MOA arrester can provide protection for electrical components up to 17.5kV, such as transformers, equipment, cables and accessories, which may subject to over voltage and transients resulting from lightning and switching. Designed to comply with the bolted-type Tee
1. Connecting Interface
Interface designed to fit with the Tee connector WEB(K)III 15/630
2. Internal Screen
Moulded EPDM conductive rubber to control electrical stress
3. External Screen
Moulded EPDM conductive rubber ensure the connector touchable
4. Insulation
Moulded EPDM insulating rubber to ensure excellent electrical properties
5. Copper Connecting Pipe
Connect the lugs between cable and surge arrester
6. Surge Arrester
Metal oxide valve elements.
7. Earth connection
The surge arrester is connected to the earth by an earth braid that manages short circuit currents.
8. Earth Lead
Earth the external screen
