Composite Line Post Insulator 36kV With Horizontal Clamp
Application: High-voltage Material: Composite Polymer Structure: Line Post Insulator Type: B Type Insulator Connection Method: Flange/Horizontal Clamp
- English
- Chinese
Application: High-voltage Material: Composite Polymer Structure: Line Post Insulator Type: B Type Insulator Connection Method: Flange/Horizontal Clamp
| Typical Line Voltage (kV) |
Section Length (mm) |
Dry Arcing Distance (mm) |
Leakage Distance (mm) |
Specified Cantilever Load (SCL, kN) |
Max. Design Cantilever Load (MDCL, kN) |
1min. Power Frequency Withstand Voltage (Wet) (kV) |
Lightning Impulse Withstand Voltage (kV) |
| 69 | 688±15 | 520 | 1465 | 32.9 | 14.7 | 175 | 330 |
